Downlight· Downlight Series
L19C
Special lighting fixtures for outdoor parking lots, tunnels, bus stops, square lighting, etc.
IPIP67
Datasheet
Above WaterWater Depth
Options
Typical Power
20W40 W60 W
Input
AC90~265
Control Method
ON OFFDALI
LED Quantity
60 PCS120 PCS180 PCS
Colour (CCT)
2200K2700K3000K4000K6500K
CRI
Ra ≥ 70Ra ≥ 80Ra ≥ 90
Beam Angle
98°
Product Dimensions
L=1514MM1014MM514MM
Material
Aluminum
| ELECTRICAL | ELECTRICAL PARAMETERS |
|---|---|
| Typical Power| Power Consumption | 20W / 40 W / 60 W |
| Input| Current | AC90~265 |
| Control Method| Control | ON OFF/ DALI |
| Cable Order| Wiring | 1 in (one in) |
| Security Level| Class | Class III |
| LIGHT SOURCE | LED LIGHT SOURCE PARAMETERS |
| LED Chip Brand| Brand | Osram |
| LED Chip Type| Type | 3030 |
| LED Quantity| Qty | 60 PCS/120 PCS/180 PCS |
| Colour (CCT)| Colour | 2200K/2700K/3000K/4000K/6500K |
| CRI| Rendering | Ra ≥ 70/Ra ≥ 80/Ra ≥ 90 |
| Typical Light Efficiency| Efficacy | >100 lm/W (3000K) · >110 lm/W (4000K) · >120 lm/W (6500K) |
| Lifetime| Life | 50,000 H |
| STRUCTURE | STRUCTURAL PARAMETERS |
| Material| Housing | Aluminum |
| Cover| Glass | PMMA, T = 3 mm |
| Beam Angle| Angle | 98° |
| Product Dimensions| Size | See DIMENSIONS drawing |
| Weight| Mass | 1.3 kg@1M |
| ENVIRONMENT | ENVIRONMENTAL PARAMETERS |
| Working Temperature| Temp | -25°C ~ +45°C |
| Storage Humidity| Humidity | 0 ~ 90% |
| IP Code| IP | IP67 |
| IK Code| IK | IK10 |
